High Voltage Color LED Annular: LC4-H

PRODUCT DESCRIPTION

One of the brightest DMX-controlled RGB LED fountain lights in the industry, the 120V, 110W LC4 is a versatile fixture designed for a variety of wet/dry applications with a total lumen output of 1,594 lumens. Ideally positioned around a nozzle for a 360° lighting effect, this 10.2” diameter annular IP68 underwater fixture has a 3.8” center opening and a depth 2.7”. Lighter than its predecessor at a mere 10 lbs., the LC4 combines a stamped copper housing, clear tempered glass lens, electrostatic-coated 316L stainless steel retaining rings, a 10’ long-life polyurethane cord, and integral power supply.

Specifications

Beam Angle Options: 8° standard. Options: 8°, 26°, 46°, 16° x 50° elliptical (consult Fountain People for custom optics)

Total Lumen Output: 1594 Lumens

Color Range: 16.7 million additive RGB colors: continuously variable intensity

Lumen Maintenance: 50% of full output for 50,000 + hours @ 50° C /122°F

Input Voltage: 120VAC ±10% 50/60 Hz

Power Consumption: 110 Watts maximum

Control Interface: DMX 512A, PLM, Switched

Control System: Fountain People, Inc. controller or third-party DMX. (LC Series lights allow for up to 170 lights per DMX universe)

Dimensions: 10.2” outer dia. x 3.8” inner dia. x 2.7” height (259.0 × 101.6 × 68.5 mm)

Weight: 10 lbs. with 10’ of cable (4.53 kg)

Housing: Stamped Copper. UNS C11000 with electrostatic-coated 316L stainless steel retaining rings; Thermally efficient

Lens: Clear tempered glass with glare and UV screening. Frosted lens optional

Cable Fixture Connection: Single cord containing 16/3 power and 22/4 twisted pair shielded communication lines; Constructed with long life polyurethane sheathing (standard)

Certifications: UL676 Compliant, FCC, RoHS Compliant

Environment: Dry / Submerged – IP68 ( reduced power/lumen output in dry environment applications)

Thermal Protection: Integral Protection Sensor

Mounting Hardware: Niche, Pedestal, Riser, L-Bracket, Custom

DOWNLOAD

Data & Dimensions
